Description +-
Power for Your Pedals
The Voodoo Lab Pedal Power 2 Plus is a universal power supply for all battery-operated guitar pedal effects. New features include two outputs that will power Line 6 modeling pedals and two outputs that can have a variable voltage sag to emulate dying carbon batteries. Like the original Pedal Power, each of its eight outputs are completely isolated, short-circuit protected, regulated, and highly filtered. The Pedal Power 2 Plus comes complete with cables and a detachable AC power cord; it is handmade in the US and carries a 5-year warranty.
Voodoo Lab Pedal Power 2 Plus Universal 8-output Power Supply at a Glance:
- Isolated outputs
- Short-circuit protection
- Toroidal transformer
Isolated outputs
Each output is completely isolated, so you won't have any ground loops or interaction between pedals that can cause hum and noise. Unlike other common ground power supplies, you can run effects that have both negative and positive grounds without difficulty.
Short-circuit protection
The Pedal Power 2 Plus's outputs are individually short-circuit protected. If you have a short in a power cable, or one of your pedals malfunctions, the Pedal Power 2 Plus will temporarily turn off the power to that pedal. All other outputs will continue to function normally, and the Pedal Power 2 Plus will not be damaged.
Toroidal transformer
Power transformers create an electric field that can cause hum and noise in your effects. Some effects, such as wahs, are particularly susceptible to this. A toroidal transformer has a specially designed core that greatly reduces this electric field. The Pedal Power 2 Plus uses this type of power transformer so that your pedalboard is quiet.
Voodoo Lab Pedal Power 2 Plus Universal 8-output Power Supply Features:
- Powers up to 8 pedals
- Isolated outputs
- Short-circuit protection
- Toroidal transformer
Included Cables:
- 5.5 x 2.1mm right-angle barrel connectors (6)
- 5.5 x 2.1mm straight barrel connectors (2)
- 5.5 x 2.5mm red barrel for L6 (1)
- 3.5mm mini plug for vintage MXR or Electro-Harmonix (1)
- 9-volt battery snap for pedals without a power jack (1)
