HH Tensor TRS-1500 Class D Amplifier, 15in Woofer, 1400W
DESCRIPTION
The Tensor TRS-1501’s design is a high-grade class D bi-amplifier providing output without restrictions, packed with intelligent on-board DSP to protect your system from failure. It also includes 4 audio modes. The stereo input and high-pass output connections provide optimal crossover separation between your full-range and sub frequencies: Creating a flawless front-of-house mix. Need more bass? No problem.
The TRE-1501 is customizable to your requirements, whether that’s DJ, live band, monitoring or announcements, the TRE-1501 has you covered with the press of a button. The integrated 2 channel mixer ensures that your devices are connected without constraints. All this contained in an ultra lightweight, multi-angle enclosure that includes 3 molded carry handles and 4 m8 suspension points. The HH tensor TRE-1501 – delivering performance and reliability.
Manufacture Detailed Specifications:
https://www.hhelectronics.com/products/tensor-tre-1501-active-full-range-enclosure
STEREO OUTPUT
HH Tensor TRE-1500 Class D Amplifier
The stereo input and high-pass output connections provide optimal crossover separation between your full-range and sub frequencies: Creating a flawless front-of-house mix. Need more bass? No problem. The shape preset boosts sub harmonic frequencies delivering a deeper bass response. All enclosed in a solid, lightweight enclosure with optimal bass porting.
TECHNICAL SPECIFICATIONS
| Power | 1400W Peak |
|---|---|
| Frequency Response (-10) | 37Hz - 250Hz (Variable 60Hz - 200Hz) |
| Max SPL (1M) (Peak) | 128 dB |
| LF Driver | 15 Inch HH designed professional bass driver |
| Inputs | 2 x Balanced Left/Right XLR |
| Outputs | 2 x Balanced Left/Right XLR link outputs, 2 x Balanced Left/Right XLR High-pass outputs |
| Controls | Volume, variable frequency crossover |
| Eq | 2 Audio modes - Flat and shape |
| Protection | Comprehensive protection and clip free limiting & clip indicator |
| Other Controls | Phase reverse switch, ground lift switch |
| Indicators | Power, clip indicator, front illuminated logo (with on/off switch) |
|---|---|
| Cabinet | 15mm plywood with 18mm MDF baffle |
| Finish | Construction rugger black spatter paint finish |
| Grille | Black heavy gauge powder-coated steel with acoustic foam backing |
| Pole Mount | 35mm Distance pole socket |
| Unit Dimensions (Hwd) | 465 x 500 x 556 mm, 18.3" x 19.7" x 21.9" |
| Unit Weight | 28Kg, 61.7 lbs |
| Carton Dimensions (Hwd) | 518 x 587 x 603 mm, 20.4" x 23.1" x 23.7" |
| Packed Weight | 31Kg, 68.3 lbs |
