Description
Yamaha PAC612VIIFM, Pacifica 600 Series, Electric Guitar, Indigo Blue
The Yamaha 600 Series
First launched in 1990, the Pacifica Series was driven by the California session scene of the day – where versatility, performance and individuality were key. Inspired by those custom shop guitars and that original vision, Pacifica 600 models represent today’s embodiment of the Pacifica concept.
Seymour Duncan Pickups in Two Configurations
All current Pacifica 600 models feature a TB-14 “Custom 5” humbucker in the bridge position for full tone with a scooped midrange and a coil tap for additional versatility. PAC611 models pair this with an SP90-1 for vintage soapbar tone, and PAC612 models use SSL-1 single-coils in the middle and neck positions for authentic 1950s chime.
Grover Locking Tuners
These tuners offer additional pitch stability by reducing string slippage – especially for guitars equipped with a vibrato bridge – without sacrificing fast string changes.
Graph Tech TUSQ Nut and String Trees
TUSQ XL is precision-engineered to couple the string vibration to the neck bringing out richness and harmonics. The Teflon-impregnated material eliminates string binding and helps to insure tuning stability, even with wide bends
Graph Tech String Saver Saddles on Hardtail Models
Paired with the original Yamaha steel bridgeplate on Pacifica 611H/HFM models, these self-lubricating saddles reduce string breakage while offering balanced tone and increased sustain.
Wilkinson VS50 6 Vibrato Bridges
Precision-machined zinc saddles are matched with hardened steel and a knife-edge baseplate for a responsive feel and stable tuning.
Key Features
- Seymour Duncan Custom 5 TB-14 and SSL-1 Pickups
- Graph Tech TUSQ Nut and String Trees
- Grover Locking Tuners
- Wilkinson VS50 Vibrato Bridge
- Alder Body with Flame Maple Veneer Top
- Maple Neck with Rosewood Fingerboard
- H/S/S Pickup Configuration with 5-Position Selector
- Push-Pull, Coil-Split Switch for Additional Tonal Options
Technical Specifications
|
Manufacturer: |
Yamaha |
|
Manufacturer Item Number: |
PAC612VIIFM |
|
First Date Available: |
|
|
Colour Name/Code |
Indigo Blue |
|
String Type: |
Steel |
|
Number of Strings |
6 |
|
Strings Spacing: |
10.8mm |
|
Strings: |
D'Addario EXL120 / 0.009-0.042 |
|
BODY |
|
|
Body Material |
Solid Adler Wood |
|
Body Type/Shape: |
Pacifica, Solid body |
|
Left-/Right-handed: |
Right-handed |
|
Top Material / Wood: |
Maple |
|
Back & Sides Material: |
Maple |
|
Body Finish: |
Gloss Polyurethane |
|
Body Colour: |
Red Metallic |
|
NECK |
|
|
Neck Shape: |
C |
|
Neck Joint: |
Bolt-On |
|
Neck Material/Wood: |
Maple |
|
Neck Finish: |
Gloss Polyurethane |
|
Scale Length: |
25-1/2" (648 mm) |
|
Neck Width @0 Fret /12th Fret |
41/51.4mm |
|
Thickness@1st Fret / 12th Fret |
20.9/22.9mm |
|
Radius: |
13-3/4” (350mm) |
|
NUT |
|
|
Nut Material: |
Graph Tech TUSQ |
|
Nut Width: |
|
|
FRET/FINGERBOARD |
|
|
Fingerboard/Fretboard Material: |
Rosewood |
|
Fingerboard Radius: |
13-3/4” (350mm) |
|
Fret Wire |
Medium |
|
Fingerboard Inlay: |
Dots |
|
Number of Frets: |
22 |
|
HARDWARE |
|
|
Bridge: |
Wilkinson VS50 6 |
|
Tremolo Arm: |
Φ5.2(Slot-in) |
|
Tuning Machines: |
Grover Locking Tuners |
|
Pickguard: |
3-Ply Black |
|
ELECTRONICS |
|
|
Pick-up Configuration: |
Combination |
|
Neck Pickup: |
Seymour Duncan SSL-1 |
|
Middle Pickup: |
Seymour Duncan SSL-1 RwRp |
|
Bridge Pickup: |
Seymour Duncan TB-14 |
|
Controls: |
1 x Master Volume, 1 x Master Tone (Push-Pull Coil Split) |
|
Switching: |
5-Position Lever Switch |
|
SHIPPING INFO |
|
|
Case/Gig Bag |
Sold Separately |
|
Manufacturer Part Number |
PAC311H RM - RED METALLIC |
|
ASIN: |
B00UWCQDW0 |
|
Country of Origin: |
Indonesia |
|
Item Weight: |
12.15 LBS |
|
Item Dimensions: |
43 x 18 x 5 inches |
